STB-18CNC-4A-2S Electric Cnc Pipe Bender

We are devoted to good quality products and people-oriented service, which wins good comments from domestic and overseas markets.

STB-18CNC-4A-2S is a powerful and fast tube bender, which can make all kinds of small tube bending or capillary tube bending, such as the oil tubes, A/C tubes, brake tubes, some tubes in electrics and so on. It is a very suitable machine for the automobile accessories tube bending, with different functions for different shapes of the tube bending. Welcome to get more information of the machine by the website or contact STM.

  • Description
  • Parameters
  • Application
  • Video
The body is made through welding, the mechanical part through assembly; using imported hydraulic system and electronic control system.
1. Fully automatic and CNC pipe bending machine;
2. Equipped with 4 programmable axis;
3. Feeding: servomotor drive with the ball screw; Rotation: servomotor drive with reducer.(the servomotor from Mitsubishi); Head left and right: servomotor drive with ball screw
4. Bending: Servomotor bending with reducer; accuracy ± 0.05°.
5. Imported hydraulic system and Mitsubishi PLC unit;
6. Automatic lubrication system for moving areas;
7. Self-diagnostic system, detecting the error immediately;
8. Multiple groups pipe-bending information storage;
9. Touch screen system and human/machine interface control provide user friendly operations;
10. Electric cabinet cooling fan and the hydraulic cooling system ensure the equipment long-time work stably under the high temperature.
